Gas-Pro PID
$1,999.98
Gas-Pro PID gives you full flexibility with a wide range of gas types to choose from. With an optional pump, the Gas-Pro PID is the perfect product addressing the requirements of a wide range of applications. Overview Gas-Pro PID utilises the Photo Ionization Detection technology to allow you to detect hundreds of Volatile Organic Compounds (VOCs).
If you are working in an environment that is high in levels of solvents, glues, paints and general VOCs, the Gas-Pro PID will monitor your safety. With its dual-coloured display, the monitor will alert the user with its 95db audible alarm and its dual-coloured visual alarm bars. PID Technology Crowcon’s PID works with a 10.6 electron volt lamp.
This sensor is the most stable sensor on the market and offers the detection of a wide range of VOCs. The sensor has an internal UV light source, which the gas sample passes through. An electron is released for gases with an ionization potential of 10.6.
User friendly:
- Top mount display – Makes it easy to read at a glance for quick decision-making
- Simple single button operation – Limited training required
- Ergonomically designed – Sits well when worn and fits easily in the hand Flexibility:
- Monitors 5 gases from many different options – Hundreds of variants to choose from
- Pumped and diffusion solutions – Offers multiple uses within one compact detector
- Multiple languages – Regionally configurable
- Automatic fail-safe flow pump plate recognition – Simple to use and no tools required
- Specific and unique Pre-Entry Check (PEC) mode – Takes away the pain of pre-entry testing
- PID correction factor – Set to target VOCs
| Size | 43 x 130 x 84mm (1.7 x 5.1 x 3.3ins) |
| Weight | 309g 4 gas (10.8oz)/ 340g pumped (11.9oz) 333g 5 gas (11.7oz)/ 362g pumped (12.7oz) |
| Alarms | Audible >95dB @ 30cm (98dB @30cm in loud mode) Visual – all angle dual red/blue LEDs Vibrating alert |
| Display | Top mount for ease of view with dual colour backlight (green/red) |
| Data logging | 125hrs at 10-second intervals (45,000 logs) |
| Event logging | Alarm, over range, calibration, bump, on/off, TWA, 1000 events |
| Battery | Rechargeable Li-ion, >14 hours (13 hours pumped operation) based on CH4, O2, H2S, CO Typical charge time 7.5 hours |
| Sampling | Internal pump as option |
| Operating temperature | -20°C to +55°C (-4°F to +131°F) |
| Storage | -25°C to +65°C (-13°F to +149°F) |
| Humidity | 10 to 95% RH |
| Ingress protection | Independently tested to IP65 |
| Approvals | IECEx: Ex db ia IIC T4 Gb Tamb -20°C to +55°C ATEX and UKCA: II 2 G Ex db ia IIC T4 Gb Tamb -20°C to +55°C UL: Class 1, Division 1, Groups A, B, C, and D UL 913, UL 60079-0 and UL 60079-11 INMETRO: Ex db ia IIC T4 Gb Tamb -20°C to +55°C
MED Directive 2014/90/EU UKCA MED (MSN1874) |
| Compliance | FCC and CE Complies with EMC Directive 2014/30/EU EN50270 and ICES-003 |
| Interface | Data connection for gas test solutions and direct to PC |
| Charging | Direct connection to multiregional power supply Vehicle charger adaptor Desktop cradle USB power and communications lead |
| Crowcon Connect Compatible? | Yes |
